Description
Striking open end wrench
Aluminium bronze (AlBz) has a magnetic permeability rating of μ 1.16 and a higher energy absorption capacity (good resistance to shocks).
Beryllium Copper (BeCu) has a magnetic permeability rating of μ 1.00 high. Hardness can reach from 280 to 350 Brinell. This alloy is well adapted for small surfaces which require strength.
Additional information
| Weight | 380 g |
|---|---|
| Dimensions | 180 mm |
| Material | AlBz, BeCu |
| Size (mm) | 14, 17, 19, 20, 22, 23, 24, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 46, 47, 50, 52, 54, 55, 56, 58, 60, 63, 65, 67, 70, 71, 75, 77, 80, 82, 85, 88, 90, 94, 95, 100, 105, 110, 115, 120, 125, 130, 135, 145, 150, 155, N/A |
| Size (in) | N/A, 11/16, 3/4, 7/8, 1, 1-1/16, 1-1/8, 1-3/16, 1-1/4, 1-5/16, 1-3/8, 1-13/32, 1-7/16, 1-1/2, 1-9/16, 1-5/8, 1-11/16, 1-3/4, 1-13/16, 1-7/8, 2, 2-1/16, 2-1/8, 2-3/16, 2-1/4, 2-5/16, 2-3/8, 2-7/16, 2-1/2, 2-9/16, 2-5/8, 2-3/4, 2-13/16, 2-15/16, 3, 3-1/8, 3-1/4, 3-3/8, 3-1/2, 3-5/8, 3-3/4, 3-7/8, 4, 4-1/8, 4-5/16, 4-9/16, 4-11/16, 4-15/16, 5-1/8, 5-1/4, 5-3/8, 5-11/16, 6 |
| Metric/Imperial Units | mm, in |
Striking open end wrench
- Description
- Size Guide
- Additional information
Description
Striking open end wrench
Aluminium bronze (AlBz) has a magnetic permeability rating of μ 1.16 and a higher energy absorption capacity (good resistance to shocks).
Beryllium Copper (BeCu) has a magnetic permeability rating of μ 1.00 high. Hardness can reach from 280 to 350 Brinell. This alloy is well adapted for small surfaces which require strength.
Additional information
| Weight | 380 g |
|---|---|
| Dimensions | 180 mm |
| Material | AlBz, BeCu |
| Size (mm) | 14, 17, 19, 20, 22, 23, 24, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 46, 47, 50, 52, 54, 55, 56, 58, 60, 63, 65, 67, 70, 71, 75, 77, 80, 82, 85, 88, 90, 94, 95, 100, 105, 110, 115, 120, 125, 130, 135, 145, 150, 155, N/A |
| Size (in) | N/A, 11/16, 3/4, 7/8, 1, 1-1/16, 1-1/8, 1-3/16, 1-1/4, 1-5/16, 1-3/8, 1-13/32, 1-7/16, 1-1/2, 1-9/16, 1-5/8, 1-11/16, 1-3/4, 1-13/16, 1-7/8, 2, 2-1/16, 2-1/8, 2-3/16, 2-1/4, 2-5/16, 2-3/8, 2-7/16, 2-1/2, 2-9/16, 2-5/8, 2-3/4, 2-13/16, 2-15/16, 3, 3-1/8, 3-1/4, 3-3/8, 3-1/2, 3-5/8, 3-3/4, 3-7/8, 4, 4-1/8, 4-5/16, 4-9/16, 4-11/16, 4-15/16, 5-1/8, 5-1/4, 5-3/8, 5-11/16, 6 |
| Metric/Imperial Units | mm, in |
Related Products
-
Add To Quote This product has multiple variants. The options may be chosen on the product pageQuick View -
Add To Quote This product has multiple variants. The options may be chosen on the product pageQuick View -
Add To Quote This product has multiple variants. The options may be chosen on the product pageQuick View -
Add To Quote This product has multiple variants. The options may be chosen on the product pageQuick View -
Add To Quote This product has multiple variants. The options may be chosen on the product pageQuick View
Material
l (mm)
(g)
Part No
Add to wishlist for Quote
Material: AlBz
Size (mm): 14
L (mm): 180
(g): 380
Part No.: AJ0014A
Add to quote:
Material: BeCu
Size (mm): 14
L (mm): 180
(g): 380
Part No.: AJ0014B
Add to quote:
Material: AlBz
Size (mm): 17
L (mm): 180
(g): 380
Part No.: AJ0017A
Add to quote:
Material: BeCu
Size (mm): 17
L (mm): 180
(g): 380
Part No.: AJ0017B
Add to quote:
Material: AlBz
Size (mm): 19
L (mm): 180
(g): 380
Part No.: AJ0019A
Add to quote:
Material: BeCu
Size (mm): 19
L (mm): 180
(g): 380
Part No.: AJ0019B
Add to quote:
Material: AlBz
Size (mm): 20
L (mm): 180
(g): 380
Part No.: AJ0020A
Add to quote:
Material: BeCu
Size (mm): 20
L (mm): 180
(g): 380
Part No.: AJ0020B
Add to quote:
Material: AlBz
Size (mm): 22
L (mm): 180
(g): 380
Part No.: AJ0022A
Add to quote:
Material: BeCu
Size (mm): 22
L (mm): 180
(g): 380
Part No.: AJ0022B
Add to quote:
Material: AlBz
Size (mm): 23
L (mm): 180
(g): 380
Part No.: AJ0023A
Add to quote:
Material: BeCu
Size (mm): 23
L (mm): 180
(g): 380
Part No.: AJ0023B
Add to quote:
Material: AlBz
Size (mm): 24
L (mm): 180
(g): 380
Part No.: AJ0024A
Add to quote:
Material: BeCu
Size (mm): 24
L (mm): 180
(g): 380
Part No.: AJ0024B
Add to quote:
Material: AlBz
Size (mm): 26
L (mm): 180
(g): 380
Part No.: AJ0026A
Add to quote:
Material: BeCu
Size (mm): 26
L (mm): 180
(g): 380
Part No.: AJ0026B
Add to quote:
Material: AlBz
Size (mm): 27
L (mm): 180
(g): 380
Part No.: AJ0027A
Add to quote:
Material: BeCu
Size (mm): 27
L (mm): 180
(g): 380
Part No.: AJ0027B
Add to quote:
Material: AlBz
Size (mm): 28
L (mm): 180
(g): 380
Part No.: AJ0028A
Add to quote:
Material: BeCu
Size (mm): 28
L (mm): 180
(g): 380
Part No.: AJ0028B
Add to quote:
Material: AlBz
Size (mm): 29
L (mm): 180
(g): 380
Part No.: AJ0029A
Add to quote:
Material: BeCu
Size (mm): 29
L (mm): 180
(g): 380
Part No.: AJ0029B
Add to quote:
Material: AlBz
Size (mm): 30
L (mm): 190
(g): 440
Part No.: AJ0030A
Add to quote:
Material: BeCu
Size (mm): 30
L (mm): 190
(g): 440
Part No.: AJ0030B
Add to quote:
Material: AlBz
Size (mm): 31
L (mm): 190
(g): 440
Part No.: AJ0031A
Add to quote:
Material: BeCu
Size (mm): 31
L (mm): 190
(g): 440
Part No.: AJ0031B
Add to quote:
Material: AlBz
Size (mm): 32
L (mm): 190
(g): 440
Part No.: AJ0032A
Add to quote:
Material: BeCu
Size (mm): 32
L (mm): 190
(g): 440
Part No.: AJ0032B
Add to quote:
Material: AlBz
Size (mm): 33
L (mm): 190
(g): 440
Part No.: AJ0033A
Add to quote:
Material: BeCu
Size (mm): 33
L (mm): 190
(g): 440
Part No.: AJ0033B
Add to quote:
Material: AlBz
Size (mm): 34
L (mm): 190
(g): 440
Part No.: AJ0034A
Add to quote:
Material: BeCu
Size (mm): 34
L (mm): 190
(g): 440
Part No.: AJ0034B
Add to quote:
Material: AlBz
Size (mm): 35
L (mm): 215
(g): 750
Part No.: AJ0035A
Add to quote:
Material: BeCu
Size (mm): 35
L (mm): 215
(g): 750
Part No.: AJ0035B
Add to quote:
Material: AlBz
Size (mm): 36
L (mm): 215
(g): 750
Part No.: AJ0036A
Add to quote:
Material: BeCu
Size (mm): 36
L (mm): 215
(g): 750
Part No.: AJ0036B
Add to quote:
Material: AlBz
Size (mm): 37
L (mm): 215
(g): 750
Part No.: AJ0037A
Add to quote:
Material: BeCu
Size (mm): 37
L (mm): 215
(g): 750
Part No.: AJ0037B
Add to quote:
Material: AlBz
Size (mm): 38
L (mm): 215
(g): 750
Part No.: AJ0038A
Add to quote:
Material: BeCu
Size (mm): 38
L (mm): 215
(g): 750
Part No.: AJ0038B
Add to quote:
Material: AlBz
Size (mm): 39
L (mm): 235
(g): 1150
Part No.: AJ0039A
Add to quote:
Material: BeCu
Size (mm): 39
L (mm): 235
(g): 1150
Part No.: AJ0039B
Add to quote:
Material: AlBz
Size (mm): 40
L (mm): 235
(g): 1150
Part No.: AJ0040A
Add to quote:
Material: BeCu
Size (mm): 40
L (mm): 235
(g): 1150
Part No.: AJ0040B
Add to quote:
Material: AlBz
Size (mm): 41
L (mm): 235
(g): 1150
Part No.: AJ0041A
Add to quote:
Material: BeCu
Size (mm): 41
L (mm): 235
(g): 1150
Part No.: AJ0041B
Add to quote:
Material: AlBz
Size (mm): 42
L (mm): 235
(g): 1150
Part No.: AJ0042A
Add to quote:
Material: BeCu
Size (mm): 42
L (mm): 235
(g): 1150
Part No.: AJ0042B
Add to quote:
Material: AlBz
Size (mm): 43
L (mm): 235
(g): 1150
Part No.: AJ0043A
Add to quote:
Material: BeCu
Size (mm): 43
L (mm): 235
(g): 1150
Part No.: AJ0043B
Add to quote:
Material: AlBz
Size (mm): 46
L (mm): 255
(g): 1400
Part No.: AJ0046A
Add to quote:
Material: BeCu
Size (mm): 46
L (mm): 255
(g): 1400
Part No.: AJ0046B
Add to quote:
Material: AlBz
Size (mm): 47
L (mm): 255
(g): 1400
Part No.: AJ0047A
Add to quote:
Material: BeCu
Size (mm): 47
L (mm): 255
(g): 1400
Part No.: AJ0047B
Add to quote:
Material: AlBz
Size (mm): 50
L (mm): 275
(g): 1600
Part No.: AJ0050A
Add to quote:
Material: BeCu
Size (mm): 50
L (mm): 275
(g): 1600
Part No.: AJ0050B
Add to quote:
Material: AlBz
Size (mm): 52
L (mm): 275
(g): 1600
Part No.: AJ0052A
Add to quote:
Material: BeCu
Size (mm): 52
L (mm): 275
(g): 1600
Part No.: AJ0052B
Add to quote:
Material: AlBz
Size (mm): 54
L (mm): 300
(g): 1800
Part No.: AJ0054A
Add to quote:
Material: BeCu
Size (mm): 54
L (mm): 300
(g): 1800
Part No.: AJ0054B
Add to quote:
Material: AlBz
Size (mm): 55
L (mm): 300
(g): 1800
Part No.: AJ0055A
Add to quote:
Material: BeCu
Size (mm): 55
L (mm): 300
(g): 1800
Part No.: AJ0055B
Add to quote:
Material: AlBz
Size (mm): 56
L (mm): 300
(g): 1800
Part No.: AJ0056A
Add to quote:
Material: BeCu
Size (mm): 56
L (mm): 300
(g): 1800
Part No.: AJ0056B
Add to quote:
Material: AlBz
Size (mm): 58
L (mm): 320
(g): 2500
Part No.: AJ0058A
Add to quote:
Material: BeCu
Size (mm): 58
L (mm): 320
(g): 2500
Part No.: AJ0058B
Add to quote:
Material: AlBz
Size (mm): 60
L (mm): 320
(g): 2500
Part No.: AJ0060A
Add to quote:
Material: BeCu
Size (mm): 60
L (mm): 320
(g): 2500
Part No.: AJ0060B
Add to quote:
Material: AlBz
Size (mm): 63
L (mm): 320
(g): 2500
Part No.: AJ0063A
Add to quote:
Material: BeCu
Size (mm): 63
L (mm): 320
(g): 2500
Part No.: AJ0063B
Add to quote:
Material: AlBz
Size (mm): 65
L (mm): 340
(g): 3700
Part No.: AJ0065A
Add to quote:
Material: BeCu
Size (mm): 65
L (mm): 340
(g): 3700
Part No.: AJ0065B
Add to quote:
Material: AlBz
Size (mm): 67
L (mm): 340
(g): 3700
Part No.: AJ0067A
Add to quote:
Material: BeCu
Size (mm): 67
L (mm): 340
(g): 3700
Part No.: AJ0067B
Add to quote:
Material: AlBz
Size (mm): 70
L (mm): 375
(g): 4000
Part No.: AJ0070A
Add to quote:
Material: BeCu
Size (mm): 70
L (mm): 375
(g): 4000
Part No.: AJ0070B
Add to quote:
Material: AlBz
Size (mm): 71
L (mm): 375
(g): 4000
Part No.: AJ0071A
Add to quote:
Material: BeCu
Size (mm): 71
L (mm): 375
(g): 4000
Part No.: AJ0071B
Add to quote:
Material: AlBz
Size (mm): 75
L (mm): 375
(g): 4000
Part No.: AJ0075A
Add to quote:
Material: BeCu
Size (mm): 75
L (mm): 375
(g): 4000
Part No.: AJ0075B
Add to quote:
Material: AlBz
Size (mm): 77
L (mm): 375
(g): 4000
Part No.: AJ0077A
Add to quote:
Material: BeCu
Size (mm): 77
L (mm): 375
(g): 4000
Part No.: AJ0077B
Add to quote:
Material: AlBz
Size (mm): 80
L (mm): 410
(g): 6300
Part No.: AJ0080A
Add to quote:
Material: BeCu
Size (mm): 80
L (mm): 410
(g): 6300
Part No.: AJ0080B
Add to quote:
Material: AlBz
Size (mm): 82
L (mm): 410
(g): 6300
Part No.: AJ0082A
Add to quote:
Material: BeCu
Size (mm): 82
L (mm): 410
(g): 6300
Part No.: AJ0082B
Add to quote:
Material: AlBz
Size (mm): 85
L (mm): 410
(g): 6300
Part No.: AJ0085A
Add to quote:
Material: BeCu
Size (mm): 85
L (mm): 410
(g): 6300
Part No.: AJ0085B
Add to quote:
Material: AlBz
Size (mm): 88
L (mm): 445
(g): 8000
Part No.: AJ0088A
Add to quote:
Material: BeCu
Size (mm): 88
L (mm): 445
(g): 8000
Part No.: AJ0088B
Add to quote:
Material: AlBz
Size (mm): 90
L (mm): 445
(g): 8000
Part No.: AJ0090A
Add to quote:
Material: BeCu
Size (mm): 90
L (mm): 445
(g): 8000
Part No.: AJ0090B
Add to quote:
Material: AlBz
Size (mm): 94
L (mm): 445
(g): 8000
Part No.: AJ0094A
Add to quote:
Material: BeCu
Size (mm): 94
L (mm): 445
(g): 8000
Part No.: AJ0094B
Add to quote:
Material: AlBz
Size (mm): 95
L (mm): 445
(g): 8000
Part No.: AJ0095A
Add to quote:
Material: BeCu
Size (mm): 95
L (mm): 445
(g): 8000
Part No.: AJ0095B
Add to quote:
Material: AlBz
Size (mm): 100
L (mm): 485
(g): 9900
Part No.: AJ0100A
Add to quote:
Material: BeCu
Size (mm): 100
L (mm): 485
(g): 9900
Part No.: AJ0100B
Add to quote:
Material: AlBz
Size (mm): 105
L (mm): 485
(g): 9900
Part No.: AJ0105A
Add to quote:
Material: BeCu
Size (mm): 105
L (mm): 485
(g): 9900
Part No.: AJ0105B
Add to quote:
Material: AlBz
Size (mm): 110
L (mm): 510
(g): 19500
Part No.: AJ0110A
Add to quote:
Material: BeCu
Size (mm): 110
L (mm): 510
(g): 19500
Part No.: AJ0110B
Add to quote:
Material: AlBz
Size (mm): 115
L (mm): 510
(g): 19500
Part No.: AJ0115A
Add to quote:
Material: BeCu
Size (mm): 115
L (mm): 510
(g): 19500
Part No.: AJ0115B
Add to quote:
Material: AlBz
Size (mm): 120
L (mm): 545
(g): 23000
Part No.: AJ0120A
Add to quote:
Material: BeCu
Size (mm): 120
L (mm): 545
(g): 23000
Part No.: AJ0120B
Add to quote:
Material: AlBz
Size (mm): 125
L (mm): 545
(g): 23000
Part No.: AJ0125A
Add to quote:
Material: BeCu
Size (mm): 125
L (mm): 545
(g): 23000
Part No.: AJ0125B
Add to quote:
Material: AlBz
Size (mm): 130
L (mm): 575
(g): 28000
Part No.: AJ0130A
Add to quote:
Material: BeCu
Size (mm): 130
L (mm): 575
(g): 28000
Part No.: AJ0130B
Add to quote:
Material: AlBz
Size (mm): 135
L (mm): 575
(g): 28000
Part No.: AJ0135A
Add to quote:
Material: BeCu
Size (mm): 135
L (mm): 575
(g): 28000
Part No.: AJ0135B
Add to quote:
Material: AlBz
Size (mm): 145
L (mm): 640
(g): 38000
Part No.: AJ0145A
Add to quote:
Material: BeCu
Size (mm): 145
L (mm): 640
(g): 38000
Part No.: AJ0145B
Add to quote:
Material: AlBz
Size (mm): 150
L (mm): 640
(g): 38000
Part No.: AJ0150A
Add to quote:
Material: BeCu
Size (mm): 150
L (mm): 640
(g): 38000
Part No.: AJ0150B
Add to quote:
Material: AlBz
Size (mm): 155
L (mm): 640
(g): 38000
Part No.: AJ0155A
Add to quote:
Material: BeCu
Size (mm): 155
L (mm): 640
(g): 38000
Part No.: AJ0155B
Add to quote:
